iPower 5.12 Lithium Battery – 51.2V 100Ah (5.12kWh)
The iPower 5.12 is a high-performance lithium iron phosphate (LiFePO4) battery engineered for reliable energy storage in residential, commercial, and backup power systems. Built using Grade A LFP cells, this advanced battery delivers superior safety, long lifespan, and outstanding efficiency.
Designed with a sleek wall-mounted structure, the iPower 5.12 integrates seamlessly into solar and inverter systems. Its intelligent Built-In Battery Management System (BMS) ensures real-time monitoring of voltage, temperature, current, State of Charge (SoC), and State of Health (SoH) for maximum protection and performance.
With support for parallel connection of up to 16 units, this battery offers scalable energy storage for growing power needs.
🔹 Key Features
-
Grade A LiFePO4 (LFP) cells for enhanced safety and durability
-
Built-in intelligent BMS for full battery protection
-
Wall-mounted, space-saving design
-
Multiple operating modes with touch screen control
-
Coloured LCD display with Bluetooth & WiFi connectivity
-
RS485 & CAN communication support
-
Compatible with a wide range of inverter brands
-
Supports parallel connection of up to 16 units
-
High efficiency above 98%
-
Long design life of over 10 years
Technical Specifications
| Items | Description |
|---|---|
| Rated Voltage | 51.2V |
| Rated Capacity | 100Ah |
| Rated Energy | 5.12 kWh |
| Output Voltage Range | 43.2V ~ 58.4V |
| Charging Voltage | 57.6V ~ 58.4V |
| Cut-Off Voltage | 43.2V |
| Max Charging Current | 100A |
| Recommended Charging Current | 50A |
| Max Discharge Current | 100A |
| Efficiency | ＞98% |
| Dimensions (L × W × H mm) | 650 × 384 × 150 |
| Weight | ~48 kg |
| Humidity | 5% ~ 95% Relative Humidity |
| Charging Temperature | 0°C ~ 55°C |
| Discharging Temperature | -20°C ~ 60°C |
| Storage Temperature | -10°C ~ 30°C |
| Cycle Life | 8000 cycles @50% DOD, 6000 cycles @80% DOD, 4000 cycles @100% DOD (0.2C, 25°C) |
| Design Life | ＞10 Years |
| Operating Mode | Touch Screen |
