Description
The iPower 14.34 is a high-capacity lithium iron phosphate (LiFePO4) battery engineered for large-scale residential and commercial energy storage. With an impressive 14.34kWh capacity, this advanced power solution is built to handle demanding solar, hybrid, and backup power applications with efficiency and reliability.
Designed using Grade A LFP cells, the iPower 14.34 guarantees enhanced safety, long cycle life, and stable performance. Its sleek ground-standing or wall-mounted design, complete with wheels for easy positioning, makes installation simple and flexible.
The integrated intelligent Battery Management System (BMS) actively monitors temperature, voltage, current, State of Charge (SoC), and State of Health (SoH), ensuring optimal performance and long-term durability.
🔹 Key Features
-
Large 14.34kWh energy storage capacity
-
Grade A LiFePO4 (LFP) cells for superior safety and longevity
-
Built-in intelligent BMS for full protection and monitoring
-
Wheeled and wall-mounted installation options
-
Ground-standing design for easy setup
-
Coloured touch LCD screen for real-time monitoring
-
Bluetooth & WiFi connectivity
-
RS485 & CAN communication support
-
Compatible with a wide range of inverter brands
-
Supports parallel connection of up to 16 units
-
High efficiency above 98%
-
Long design life exceeding 10 years
Technical Specifications
| Items | Description |
|---|---|
| Rated Voltage | 51.2V |
| Rated Capacity | 280Ah |
| Rated Energy | 14.34 kWh |
| Output Voltage Range | 43.2V ~ 58.4V |
| Charging Voltage | 57.6V ~ 58.4V |
| Cut-Off Voltage | 43.2V |
| Max Charging Current | 150A |
| Recommended Charging Current | 50A |
| Max Discharge Current | 150A |
| Efficiency | ＞98% |
| Dimensions (L × W × H mm) | 825 × 413 × 233 |
| Weight | ~110 kg |
| Humidity | 5% ~ 95% Relative Humidity |
| Charging Temperature | 0°C ~ 55°C |
| Discharging Temperature | -20°C ~ 60°C |
| Storage Temperature | -10°C ~ 30°C |
| Cycle Life | 8000 cycles @50% DOD, 6000 cycles @80% DOD, 4000 cycles @100% DOD (0.2C, 25°C) |
| Design Life | ＞10 Years |
| Operating Mode | Touch Screen |
