Description
Product Description (Summary)
Camera
| Specification | Details |
|---|---|
| Image Sensor | 1/3″ CMOS |
| Min. Illumination | Color: 0.02 Lux @(F2.0, AGC ON) B/W: 0 Lux with IR |
| Shutter Time | 1s ~ 1/100000s |
| Day & Night | IR-cut filter with auto switch (ICR) |
| Smart IR | Yes |
| WDR | DWDR |
| S/N Ratio | >52dB |
| Angle Adjustment | Pan: 0~340°; Tilt: 0~75°; Rotate: 0~360° |
Lens
| Specification | Details |
|---|---|
| Lens Type | Fixed focal lens |
| Focal Length | 2.8mm |
| Aperture | F2.0 (Fixed) |
| Lens Mount | M12 |
| Field of View | 93°(H); 53°(V); 104.8°(D) |
| DORI Distance | Detect: 41.48m Observe: 16.46m Recognize: 8.3m Identify: 4.1m |
Illuminator
| Specification | Details |
|---|---|
| IR LEDs | 1 |
| IR Distance | Up to 30m |
| Wavelength | 850nm |
Compression & Audio
| Specification | Details |
|---|---|
| Video Compression | S+265 / H.265 / H.264 |
| Video Bit Rate | 32kbps ~ 4Mbps |
| Audio Compression | G.711A / G.711U |
| Audio Sampling | 8kHz |
| Specification | Details |
|---|---|
| Max Resolution | 2MP (1920×1080) @ 30fps |
| Main Stream | Up to 1080p (25/30fps) |
| Sub Stream | Multiple lower resolutions supported |
| Image Enhancements | BLC, HLC, AGC, 3D DNR, Defog |
| White Balance | Multiple modes (Auto, Manual, Lighting presets) |
| Privacy Mask | 4 static areas |
| OSD | Custom text overlay (1 region) |
Features & Network
| Specification | Details |
|---|---|
| Alarms | Motion Detection; IP Address Conflict |
| Protocols | RTSP, HTTP, TCP/IP, DHCP, DNS, NTP, IPv4, SSH |
| ONVIF | Profile S / T |
| System Compatibility | ONVIF, SDK, CGI, Milestone |
| Remote Users | Up to 2 |
| Client Software | Easy7 VMS |
| Web Browsers | IE10+, Firefox52+, Edge89+, Safari11+, Chrome57+ |
Interface & General
| Specification | Details |
|---|---|
| Network Interface | 1× RJ-45 (10/100 Base-T) |
| Built-in Mic | Yes (1×) |
| Power Supply | PoE (IEEE 802.3af), Max 2W |
| Operating Temp | -30°C ~ 60°C |
| Protection | 4000V Surge, 6000V ESD |
| Dimensions | 94×94×78mm |
| Weight | 0.17kg |
